155M Bidi SFP Module 1310 / 1550nm , Simplex 20km LC WDM SFP Module

Brand Name : AEO

Certification : CE, FCC, ROHS

Place of Origin : China

MOQ : 1 piece

Price : negotiation

Payment Terms : T/T

Supply Ability : 10000 pcs/month

Delivery Time : 5-8 working days

Packaging Details : package and carton

Bandwidth : 155M

Distance : 20km

Optical Connector : LC

Temperature Range : 0°C~70°C

Item : 155M Copper Module

Optical Wavelength : 3.3v

Contact Now

155M Bidi SFP Module 1310/1550nm 20km LC WDM SFP Transceiver Simplex SFP

Technical Parameters

Up to 155Mb/s Data Links

Hot-Pluggable

Single LC connector

Up to 20 km on 9/125μm SMF

1310nm FP laser transmitter

1550nm PIN photo-detector

Single +3.3V Power Supply

Monitoring Interface Compliant with SFF-8472

Maximum Power <1W

Industrial /Extended/ Commercial operating temperature range: -40°C to 85°C/-5°C to 85°C/-0°C to 70°C Version available

RoHS compliant and Lead Free

Product Overview

SFP Transceivers are a high performance, cost effective module which have a single LC optics interface. They are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) and Digital diagnostics functions are available via the 2-wire serial bus specified in SFF-8472. The receiver section uses a PIN receiver and the transmitter uses a 1310 nm FP laser, up to 19dB link budge ensure this module SONET OC-3 / SDH STM -1 20km application.

Key Feature

Up to 155Mb/s Data Links

Hot-Pluggable

Single LC connector

Up to 20 km on 9/125μm SMF

1310nm FP laser transmitter

1550nm PIN photo-detector

Single +3.3V Power Supply

Monitoring Interface Compliant with SFF-8472

Maximum Power <1W

Industrial /Extended/ Commercial operating temperature range: -40°C to 85°C/-5°C to 85°C/-0°C to 70°C Version available

RoHS compliant and Lead Free

Product Pictures

155M Bidi SFP Module 1310 / 1550nm , Simplex 20km LC WDM SFP Module

Packaging & Shipping

● All of our package are international standard package

● We will deliver our products as soon as the order confirmed

155M Bidi SFP Module 1310 / 1550nm , Simplex 20km LC WDM SFP Module
